Keypad Fibra Black
Manufacturer overview
Wired keypad with touch buttons
Control simplicity at its best. Superior KeyPad Fibra is a reliable, easy-to-use tool for managing security and automation devices. With multiple code options, the keypad offers transparent control over a facility. The built-in panic button and duress code make the device indispensable in emergencies. Its sleek, minimalist design appeals to end users, while PROs benefit from easy installation. All settings are configurable remotely via Ajax apps.
Suitable for any location. Superior KeyPad Fibra utilizes multiple types of access codes for user authentication and system control. Each code entry and user action is logged and displayed in Ajax apps. The apps also allow PROs and users with admin rights to create and configure access codes at any time without visiting the site.
Where control meets flexibility. Superior KeyPad Fibra utilizes multiple types of access codes for user authentication and system control. Each code entry and user action is logged and displayed in Ajax apps. The apps also allow PROs and users with admin rights to create and configure access codes at any time without visiting the site.
Keypad code. The keypad code enables multiple users to control the system. Since this code is general, all actions performed with it are logged under the keypad name. Each Superior KeyPad Fibra can have its own general code, or the same code can be assigned to multiple keypads within a facility. This ensures easy access across different entry points.
User code. Superior KeyPad Fibra allows users to set personal codes. This can be done via Ajax apps without assistance from an installer or admin, reducing the risk of code exposure. Actions performed with a user code are logged under the user’s name, and the CMS receives notifications with the user ID. As a result, this ensures traceable control over the facility.
Unregistered user code. Superior KeyPad Fibra supports up to 99 codes for users without Ajax accounts. They are meant to eliminate the need to create accounts for temporary users, such as cleaning services or realtors. Instead, a code can be assigned in the hub settings in just a few clicks. In this case, actions are logged under the assigned code name.
Specifications
| Line connection |
4-core cable |
| Fibra line length |
up to 6,500 ft |
| Sensor type |
Capacitive |
| Duress code |
50 personal codes |
| Functional button |
Panic button |
| Codes |
50 personal codes |
| ACE Type |
Type B |
| Protection against forgery |
device authentication |
| Keypad’s operating voltage range |
5−26 V⎓, up to 487 mW |
| Keypad’s nominal operating voltage |
24 V⎓ |
| Quiescent keypad’s current consumption at nominal voltage |
0.16 mA |
| Maximum keypad’s current consumption at nominal voltage |
20.3 mA |
| Maximum output peak-to-peak ripple voltage |
220 mV |
| Protection class |
IP50, IK04 |
| Dimensions |
5.90″ × 4.05″ × 0.79″ |
| Weight of the white device |
6.38 oz |
| Weight of the black device |
5.85 oz |
| Operating temperature range |
from 14 °F to 104 °F |
| Operating humidity |
up to 75% |
| Warranty |
24 months |
