32Ch NVR VIGI NVR4032H
Manufacturer overview
Security Never Shuts Down. VIGI NVR4032H 32 Channel Network Video Recorder
Dual Ethernet Ports Design. Allows for the implementation of two different gateways
Auto Initialize for Quick Configuration. Just click “Auto Initialize” to set up basic IPC and hard disk parameters, greatly reducing your configuration time.
Specifications
| IP Video Input |
32-Channel |
| Incoming Bandwidth |
320 Mbps |
| Outgoing Bandwidth |
320 Mbps |
| HDMI Output Resolution |
1 Channel, Resolution: 3840x2160/30Hz,1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| VGA Output Resolution |
1 Channel, Resolution: 1920x1080/60Hz,1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| Video Output Mode |
HDMI and VGA Independent / Simultaneous Output |
| Multi-View Display |
1/4/6/8/9/16/25/32/36 |
| Audio Compression |
G.711A/G.711U/G.726 |
| Video Compression |
H.265+/H.265/ H.264+/H.264 |
| Record Resolution |
8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback |
16-Channel |
| Capability |
• 25fps:16-ch@2MP、32-ch@720P• 30fps:4-ch@8MP、6-ch@5MP、8-ch@4MP |
| Record Mode |
• Manual Recording• Scheduling Recording• Motion Detection Recording |
| Playback Mode |
• Instant Playback• Regular Playback• Tag Playback• Event Playback |
| Backup Mode |
• Regular Backup• Video Clip Backup |
| Playback Function |
• Play• Pause• Stop• Fast Forward• Fast Backward• Play By Frame• Full Screen• Video Clip• Export Clip• Digital Zoom• Lock Recording• Audio On/Off |
| Protocol |
UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP, IPv6, SNMP |
| Mobile Phone Access |
Android, iOS |
| Web Browser |
Chrome (57+), Firefox (52+), Edge (91+) |
| Interoperability |
ONVIF Profile S/T, CGI |
| Network Interface |
2, RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface |
| USB Interface |
2 Front USB 2.0 Ports, 1 Rear USB 3.0 Port |
| Audio Interface |
1-ch RCA Input; 1-ch RCA Output |
| Alarm In/Out |
16/4 |
| Serial Interface |
1, RS232 |
