Synology WRX560 Dual-band Wi-Fi 6 Router - Powered by SRM
Designed for the Modern Smart Home
The WRX560 is a feature-packed high-performance router designed for busy households and home offices. Take advantage of mesh network capability for seamless whole-house coverage. Support for 3Gbps wireless speeds and up to 150× connected devices ensures fast, uninterrupted internet connectivity, even in busy network environments. Powered by the constantly evolving Synology Router Manager operating system (SRM), the WRX560 is designed to make securing and managing your network simple.
Features
- Speedy Performance - Dual-band Wi-Fi 6 with 5.9 GHz support and configurable WAN/LAN 2.5GbE port enable fast wireless and wired transfers
- Advanced Network Security - Comprehensive network security provided through Threat Prevention, VLAN segmentation, and WPA3 support
- Mesh Ready - Standalone router that can be incorporated into a mesh system for whole home coverage
- Safe Internet Access for Families - Parental controls and web filtering keep your family protected
- Easy Setup and Management - DS router app provides easy-to-follow setup and network management through your mobile device
- Simple Remote Access - Comprehensive VPN server solution with remote desktop and site-to-site tunnelling enables flexible and secure remote connectivity
Specifications
Cpu
- Quad Core 1.4GHz
- Hardware Acceleration Engine: Layer 4 / Layer 7
Memory
Wireless (Wi-Fi 6 / IEEE 802.11ax)
- 4×4 MIMO High-Performance Internal Antenna (5.0GHz)
- 2×2 MIMO High-Performance Internal Antenna (2.4GHz)
- 2.4GHz: 600Mbps
- 5.0GHz: 2,400Mbps
- Simultaneous Dual-Band Wi-Fi
- Wi-Fi Encryption: WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA3-Personal/Enterprise, OWE
Lan / Wan
- WAN Ports: 1× 2.5GbE (Dual WAN)
- LAN Ports: 3× Gigabit, 1× Gigabit
External Ports
- 1× USB3.2 Gen1 (DC5V 0.9A Power Output)
Physical
- Dimensions (H × W × D): 223 × 194 × 65mm
- Weight: 1.35kg
Power
- AC Input Power Voltage: 100~240VAC
- Power Frequency: 50/60Hz, Single Phase
- Power Consumption: 10.8W (Access), 7.94W (Idle)
Environment
- Operating Temperature: 5~40°C
- Storage Temperature: -20~60°C
- Relative Humidity: 5~95% RH
- RoHS Compliant
SRM (Synology Router Manager) SPECIFICATIONS
Wireless Capabilities
- Maximum Number of Wi-Fi SSID: 10×
- Seamless Roaming: 802.11k/v/r Support
- Guest Network: Yes
- Scheduled Wi-Fi: Yes
- WPS2.0: Yes
- 3G/4G Dongle and Tethering: Yes
- Primary Wi-Fi Point: Yes
- Recommended Maximum Number of Wi-Fi Points: 1× Primary + 6× Wi-Fi Points (Wireless Uplink), 1× Primary + 12× Wi-Fi Points (Wired Uplink)
- Maximum Connected Devices: 150×
Network Features
- Dual WAN: Yes
- IPv4 / IPv6 Support: Yes
- DHCP Server / Client / Static IP: Yes
- NAT: Yes
- LAN/WLAN IGMP Snooping: Yes
- Policy Route: Yes
- Static Route: Yes
- Maximum DHCP Reservations: 500×
- Maximum IPv4 Static Routes: 100×
- Maximum IPv6 Static Routes: 100×
Vpn
- VPN Server (WebVPN, SSL VPN, SSTP, OpenVPN, L2TP/IPSec, PPTP, Site-to-Site VPN)
- VPN Client (PPTP, OpenVPN, L2TP/IPSec)
- Maximum Site-to-Site VPN Tunnels: 10×
- Maximum OpenVPN Connections: 20×
Security
- Firewall
- DoS Protection
- Auto Block
- SSL Certificate Support
- Two-Factor Authentication
- Safe Access (Web Filter, Time Quota, Schedule, URL Block/Allow List)
- Threat Prevention (Deep Packet Inspection)
Traffic Management
- Application Layer (L7) Quality of Service (QoS)
- Bandwidth Control per Device
- Live Traffic Monitoring
- Historical Statistics (Daily, Weekly, Monthly, Annual)
- Traffic Reports Export (.csv, .html)
Download Station
- Maximum Concurrent Download Tasks: 20×
- Maximum Concurrent BT Download Tasks: 20×
Media and Services
- Media Server: DLNA Compliance
- DNS Server: Yes
- RADIUS Server: Yes
Mobile Apps
- DS Router (Android/iOS)
- VPN Plus (Android/iOS)
- DS Get (Android)
- DS File (Android/iOS)
Management
- Synology Router Manager (SRM)
- QuickConnect & DDNS
- Wake on LAN (WOL)
- SNMP
- SSH
- Configuration Backup & Restore
- User Account Management
File & USB/SD Card Support
- File System: EXT4, FAT, NTFS, HFS+
- Protocol Support: CIFS/SMB, AFP, FTP/FTPS, WebDAV
- Apple Time Machine: Yes
- Shared Folder Privileges: Yes
Warranty
