Synology RackStation RS822RP+ 4-Bay NAS with Redundant Power - AMD Ryzen V1500B 2.2GHz Quad-Core CPU, 2GB RAM, Diskless
Flexible and Versatile Storage for Effective Data Management, Synology RackStation RS822RP+ is a 4-bay rackmount NAS enclosed in a compact 1U chassis. Running the powerful Synology DiskStation Manager (DSM) operating system, it is ideal for data backup, sharing and synchronisation. Its small size, stable performance, and storage scalability makes it suitable for branch offices and small to medium-sized businesses with ever-increasing data management needs. The RS822RP+ features a redundant power supply for an extra edge in service continuity.
Features
- High Performance - Over 2,103/1,074MB/s sequential read/write throughput supports stable data transfers
- Redundant Power - Maximise uptime with a redundant power supply
- Easy Expansion - Scale up to 8× drives with one Synology RX418 Expansion Unit
- Flexible Connectivity - Four 1GbE ports support network failover and load balancing, with optional 10/25GbE expansions available
- SSD Cache Support - Boost random IOPS performance with optional SSD cache
Specifications
Hardware
Cpu
- AMD Ryzen V1500B
- 4-Core 2.2GHz
- Hardware Encryption Engine (AES-NI)
Memory
- 8GB DDR4 ECC SODIMM
- Total Memory Slots: 2×
- Maximum Memory Capacity: 32GB (2× 16GB)
Drive Bays
- 8×
- Maximum Drive Bays with Expansion Unit: 18 (2× RX418)
- Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA SSD
- Hot Swappable Drive: Yes
External Ports
- 2× RJ45 1GbE LAN Port (with Link Aggregation / Failover support)
- 2× USB3.2 Gen1 Port
PCIe
- 1× Gen3 x8 Slot (x4 link)
File System
Internal Drives
External Drives
- Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT
Appearance
- Form Factor (RU): 2U
- Rack Installation Support: 4-Post 19" Rack (Synology Rail Kit – RKS-02)
- System Fan: 40mm × 2pcs
Power and Environment
Power Supply
AC Input Power Voltage
- 100–240VAC
- 50/60Hz, Single Phase
Power Consumption
- 44.76W (Access) / 16.77W (HDD Hibernation)
Operating Temperature
Storage Temperature
Relative Humidity
Dsm Specifications
Storage Management
- Maximum Single Volume Size: 108TB
- Btrfs (Write-Once): Yes
- SSD TRIM: Yes
- Supported RAID Types: Synology Hybrid RAID (SHR), Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
File Services
- Maximum Concurrent SMB/AFP/FTP Connections: 1,000+
- Windows ACL Integration: Yes
- NFS Kerberos Authentication: Yes
Accounts and Shared Folder
- Maximum Local User Accounts: 2,048×
- Maximum Local Groups: 256×
- Maximum Shared Folders: 512×
Virtualisation and Enterprise Integration
- VMware vSphere
- Microsoft Hyper-V
- Citrix
- OpenStack
Backup and Data Protection
- Hyper Backup
- Snapshot Replication
- Synology High Availability
- Active Backup for Business
Surveillance Station
Maximum IP Cameras (H.264)
- 720p: 40× channels, 1,200 FPS
- 1080p: 40× channels, 600 FPS
- 3M: 40× channels, 480 FPS
- 5M: 40× channels, 320 FPS
- 4K: 20× channels, 200 FPS
Warranty
- 3-Year Hardware Warranty (Extendable to 5-Years with EW202)
