SYNOLOGY RACKSTATION RS3621RPXS 12-BAY 2U RACKMOUNT NAS WITH REDUNDANT POWER - INTEL XEON D-1531 2.2GHZ 6-CORE CPU, 8GB ECC RAM, DISKLESS

Synology RackStation RS3621RPxs 12-Bay 2U Rackmount NAS with Redundant Power - Intel Xeon D-1531 2.2GHz 6-Core CPU, 8GB ECC RAM, Diskless

Powerful Storage. Built For Business Continuity.

The Synology RackStation RS3621RPxs is a 12-bay 2U rackmount NAS designed to centralise business data, protect critical workloads and support growing storage requirements. Its Intel Xeon D-1531 six-core processor operates at 2.2GHz, with turbo speeds up to 2.7GHz, while 8GB of ECC DDR4 memory helps maintain data integrity and can be expanded to 64GB. Dual redundant power supplies and hot-swappable system fans support service continuity, and twelve SATA drive bays provide flexible HDD or SSD deployment. Four Gigabit Ethernet ports and two PCIe expansion slots enable networking and SSD-cache upgrades. Capacity can grow to 36 bays using two optional expansion units. Powered by Synology DiskStation Manager, the diskless RS3621RPxs brings file sharing, backup, virtualisation, collaboration and surveillance together in one manageable platform.

Features

• Twelve-Bay Rackmount Storage - Supports twelve compatible 3.5" SATA HDDs or 2.5" SATA SSDs
• Diskless Configuration - Allows drives to be selected around storage capacity, performance and protection requirements
• Intel Xeon Processing - A six-core, twelve-thread processor handles demanding business applications and concurrent workloads
• Turbo Performance - Operates at 2.2GHz with turbo speeds up to 2.7GHz
• ECC System Memory - Includes 8GB DDR4 ECC memory to help detect and correct memory errors
• Expandable Memory - Four UDIMM slots support up to 64GB of system memory
• Redundant Power Supplies - Dual PSU modules help maintain operation if one module fails or a power cable is disconnected
• High Read Performance - Delivers up to 4,718MB/s sequential read throughput and 189,098 4K random read IOPS under Synology test conditions
• Four Gigabit LAN Ports - Provides four integrated 1GbE RJ45 connections for flexible network deployment
• Dual PCIe Expansion Slots - Supports compatible network cards and SSD-cache adapters
• 10/25GbE Upgrade Support - Optional compatible network cards provide faster connectivity for demanding workloads
• SSD Cache Support - Compatible SATA SSDs or optional NVMe adapter cards and SSDs can accelerate frequently accessed data
• Expandable to Thirty-Six Bays - Supports two optional RX1217 or RX1217RP expansion units
• Hot-Swappable Drive Bays - Allows compatible drives to be replaced without shutting down the system
• Hot-Swappable System Fans - Supports fan replacement while the system remains powered on
• Btrfs Data Protection - Supports snapshots, file self-healing with suitable RAID configurations, and flexible storage quotas
• Flexible RAID Options - Supports RAID F1, Basic, JBOD and RAID 0, 1, 5, 6 and 10
• Centralised Backup - Protects computers, servers, virtual machines and supported cloud accounts through Synology backup applications
• Virtualisation Support - Integrates with VMware vSphere, Microsoft Hyper-V, Citrix XenServer and OpenStack environments
• Synology High Availability - Pairs two identical units in an active-passive cluster to help minimise service downtime
• Surveillance Capabilities - Supports up to 75 IP cameras, depending on recording settings and system workload
• Five-Year Warranty - Includes a five-year limited hardware warranty

Specifications

Processor

• CPU Model: Intel Xeon D-1531
• CPU Quantity: 1
• CPU Architecture: 64-bit
• CPU Cores: 6
• CPU Threads: 12
• Base Frequency: 2.2GHz
• Maximum Turbo Frequency: 2.7GHz
• Hardware Encryption Engine: Yes

Memory

• Installed Memory: 8GB DDR4 ECC UDIMM
• Memory Configuration: 1× 8GB
• Memory Slots: 4×
• Maximum Memory Capacity: 64GB, 4× 16GB

Storage

• Installed Drives: None, Diskless
• Drive Bays: 12×
• Supported Drive Types: 3.5" SATA HDD and 2.5" SATA SSD
• Maximum Drive Bays with Expansion: 36×
• Supported Expansion Units: Up to 2× Synology RX1217/RX1217RP, Sold Separately
• Hot-Swappable Drives: Yes
• Maximum Single Volume Size with Standard Memory: 108TB
• Maximum Single Volume Size with 32GB Memory: 200TB
• Maximum Single Volume Size with 64GB Memory: 1PB, RAID 6 Groups Only and Subject to Peta Volume Requirements
• Maximum Internal Volumes: 128
• SSD Read/Write Cache: Supported
• SSD TRIM: Supported
• RAID Group: Supported
• Supported RAID Types: RAID F1, Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6 and RAID 10
• Internal File Systems: Btrfs, ext4
• External File Systems: Btrfs, ext4, ext3, FAT32, NTFS, HFS+ and exFAT

Network And Connectivity

• Ethernet Ports: 4× 1GbE RJ45
• USB Ports: 2× USB3.2 Gen1 Type-A
• Expansion Ports: 2× InfiniBand-Type Storage Expansion Ports
• PCIe Expansion: 2× PCIe Gen 3 x8 Slots, Each with an x8 Link
• Wake on LAN/WAN: Supported

Physical

• Form Factor: 2U Rackmount
• Dimensions (H × W × D): 88 × 482 × 724mm
• Weight: 14.5kg
• Drive Trays: Lockable
• Rack Compatibility: 4-Post 19" Rack with an Optional Rail Kit
• Compatible Rail Kit: RKS-02, Sold Separately

Cooling And Acoustics

• System Fans: 4× 80×80mm
• Fan Modes: Full-Speed Mode, Cool Mode, Quiet Mode
• Hot-Swappable System Fans: Yes
• Noise Level: 50.2dB(A), Under Manufacturer Test Conditions

Power

• Power Supply Modules: 2× Redundant PSUs
• PSU Rating: 500W or 550W per Module, Depending on Hardware Revision
• Input Voltage: 100~240V AC
• Power Frequency: 50/60Hz, Single Phase
• Power Consumption During Access: 140.01W
• Power Consumption During HDD Hibernation: 65.94W
• Scheduled Power On/Off: Supported
• Power Recovery: Supported

Operating Environment

• Operating Temperature: 0~35°C
• Storage Temperature: -20~60°C
• Operating Humidity: 8~80% RH
• Storage Humidity: 5~95% RH
• RoHS Compliant: Yes

Software And Services

• Operating System: Synology DiskStation Manager
• Supported File Protocols: SMB, AFP, NFS, FTP, WebDAV and Rsync
• Maximum SMB Connections: 1,000, Under Synology FSCT Test Conditions
• Backup Solutions: Synology Active Backup Suite, Hyper Backup and Snapshot Replication
• Virtualisation Support: VMware vSphere, Microsoft Hyper-V, Citrix XenServer and OpenStack
• Maximum iSCSI Targets: 128
• Maximum LUNs: 256
• Maximum Supported IP Cameras: 75, Depending on Resolution, Codec and Frame Rate
• Included Surveillance Device Licences: 2
• Synology High Availability: Supported

Warranty

• Limited Hardware Warranty: 5 Years
