SYNOLOGY DISKSTATION DS925NEO+ 4-BAY NAS - AMD RYZEN V1500B 2.2GHZ QUAD-CORE CPU, 4GB RAM, DISKLESS

Synology DiskStation DS925neo+ 4-Bay NAS - AMD Ryzen V1500B 2.2GHz Quad-Core CPU, 4GB RAM, Diskless

Flexible, High-Speed Storage for Growing Data

The Synology DiskStation DS925neo+ is a versatile four-bay NAS designed for home offices, creative professionals and growing businesses. Its AMD Ryzen V1500B quad-core processor, 4GB of expandable DDR4 memory and dual 2.5GbE network ports provide responsive performance for file sharing, synchronisation, backup, virtualisation and surveillance. Four hot-swappable SATA drive bays support compatible 3.5" hard drives and 2.5" SSDs, while two M.2 NVMe slots can be used for SSD caching or storage pools. Storage can be expanded from four to nine bays using an optional Synology DX525 expansion unit. Powered by Synology DiskStation Manager, the DS925neo+ provides an intuitive private-cloud platform with comprehensive data protection, collaboration, multimedia and monitoring applications.

Features

• Powerful AMD Ryzen Processor - Quad-core, eight-thread processor provides capable performance for simultaneous storage and application workloads
• Four-Bay Storage - Supports compatible 3.5" SATA HDDs and 2.5" SATA SSDs
• Expandable to Nine Bays - Add an optional Synology DX525 five-bay expansion unit as storage requirements grow
• Dual 2.5GbE Networking - Provides fast network transfers with support for failover and load balancing through Link Aggregation
• High Sequential Performance - Delivers up to 536MB/s sequential read and 557MB/s sequential write throughput
• Dual M.2 NVMe Slots - Enable SSD read/write caching or create compatible SSD storage pools without occupying the main drive bays
• Expandable Memory - Supplied with 4GB DDR4 non-ECC memory and supports up to 32GB across two SODIMM slots
• Hot-Swappable SATA Bays - Replace compatible SATA drives without shutting down the system
• Comprehensive RAID Support - Supports Synology Hybrid RAID, Basic, JBOD and RAID 0, 1, 5, 6 and 10
• Integrated Data Protection - Supports Active Backup Suite, Hyper Backup, Snapshot Replication and immutable snapshots
• Private-Cloud Collaboration - Synology Drive, Photos, Office and other DSM applications simplify secure file access and teamwork
• Video Surveillance Ready - Synology Surveillance Station supports extensive IP-camera integration and includes two camera licences
• Quiet, Efficient Cooling - Dual 92mm fans offer Full-Speed, Cool and Quiet operating modes
• Compact Desktop Design - Provides expandable business-class storage in a space-efficient enclosure

Specifications

Processor

• CPU: AMD Ryzen V1500B
• CPU Architecture: 64-bit
• Cores: 4
• Threads: 8
• Frequency: 2.2GHz
• Hardware Encryption Engine: Supported

Memory

• Installed Memory: 4GB DDR4 non-ECC SODIMM
• Configuration: 1× 4GB
• Memory Slots: 2
• Maximum Capacity: 32GB Using 2× 16GB Modules

Storage

• SATA Drive Bays: 4
• Supported SATA Drives: 3.5" SATA HDD or 2.5" SATA SSD
• M.2 Slots: 2× M.2 2280 NVMe
• Maximum Bays with Expansion: 9 Using 1× Synology DX525
• Maximum Raw Internal Capacity: Up to 96TB Using Four 24TB Drives
• Maximum Raw Expanded Capacity: Up to 216TB Using Nine 24TB Drives
• SATA Drive Hot-Swap: Supported
• M.2 Hot-Swap: Not Supported
• M.2 Functions: SSD Read/Write Caching and Compatible Storage-Pool Creation
• Maximum Internal Volumes: 32
• Maximum Single Volume: 108TB or up to 200TB With 32GB Memory and a Supported Configuration

Raid And File Systems

• Supported RAID: Synology Hybrid RAID, Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6 and RAID 10
• Internal File Systems: Btrfs and ext4
• External File Systems: Btrfs, ext4, ext3, FAT32, NTFS, HFS+ and exFAT
• Supported File Protocols: SMB, AFP, NFS, FTP, WebDAV and Rsync

Networking And Connectivity

• LAN Ports: 2× RJ45 2.5GbE
• USB Ports: 2× USB3.2 Gen 1
• Expansion Port: 1× USB Type-C Expansion Port
• Network Features: Link Aggregation, Failover, Load Balancing and Wake on LAN/WAN
• Security Slot: Kensington Security Slot

Performance

• Sequential Read: Up to 536MB/s
• Sequential Write: Up to 557MB/s

Cooling And Acoustics

• System Fans: 2× 92mm
• Fan Modes: Full-Speed, Cool and Quiet
• Rated Noise Level: 20.5dB(A)
• Front LED Brightness: Adjustable

Power

• Power Adapter: 100W
• AC Input: 100~240V AC, 50/60Hz, Single Phase
• Power Consumption: 37.91W During Access
• HDD Hibernation Consumption: 12.33W
• Power Recovery: Supported
• Scheduled Power On/Off: Supported

Physical Specifications

• Dimensions: 166 × 199 × 223mm
• Weight: 2.26kg
• Operating Temperature: 0~40°C
• Storage Temperature: -20~60°C
• Operating Humidity: 8~80% RH
• Storage Humidity: 5~95% RH
• Maximum Operating Altitude: 5,000m

Certifications And Warranty

• Certifications: FCC, CE, BSMI, VCCI, RCM, UKCA, EAC, CCC, KC and BIS
• Environmental Compliance: RoHS
• Warranty: Three-Year Limited Hardware Warranty, Extendable to Five Years in Supported Regions

Notes

• Compatible drives are mandatory. Confirm support on Synology’s compatibility list before purchasing or installing drives
• Raw-capacity figures are based on 24TB drives. Usable capacity is lower and varies according to the installed drives, RAID configuration and file system
• Surveillance Station includes two camera licences. Additional cameras require separately purchased licences
