TP-Link NVR1004H-4P VIGI 4-Channel PoE+ Network Video Recorder (NVR)
This VIGI network video recorder delivers exceptional performance with 4K HDMI video output and 16MP decoding capacity, providing sharp image definition and a four-channel display to capture every detail from multiple angles.
Designed for convenience, it supports simplified deployment with PoE+ technology, allowing both power and data transmission through a single RJ45 cable-no additional power adapters required. With 4-channel simultaneous playback, you can review footage from up to four cameras at once, adjust playback speed, and quickly locate events on the video timeline.
Using advanced H.265+ compression, the system transmits high-quality video without increasing bandwidth usage, saving disk space and reducing network load while maintaining crystal-clear image quality. ONVIF compatibility ensures seamless integration with VIGI and other camera brands, providing flexibility for building a powerful and varied surveillance network.
The plug-and-play feature enables automatic detection and activation of new VIGI IP cameras, simplifying installation. Supporting up to 10TB of continuous recording, it secures your footage for 24/7 access.
With remote monitoring available through the VIGI app and VIGI Security Manager, you can easily manage and view your system from anywhere. Two-way audio allows for real-time voice communication directly through the interface, ideal for interactive management. Additionally, its 80Mbps video access bandwidth ensures smooth performance, capable of managing up to four 4MP cameras simultaneously.
Features
- 4K HDMI Video Output & 16MP Decoding Capacity: Sharp image definition up to 8MP and a 4-channel display ensures you capture every detail, from every angle
- Simplified Deployment with PoE+: Easily connect and power your PoE camera with one RJ45 cable transmitting both data and power
- No power adapter needed
- 4-Channel Simultaneous Playback: Replay the feed from up to 4 cameras at the same time, increase replay speed and find events in the video schedule to easily review footage
- H.265+: Without using any extra bandwidth, your camera transmits compressed crystal-clear video to save disk space, ease network loads and reduce monitoring costs without sacrificing image quality
- ONVIF Ensures Compatibility: Easily add IPCs from VIGI and other brands to establish a powerful and varied network thanks to barrier-free compatibility
- Plug & Play: Allows new and unused VIGI IP Cameras to be added automatically to the new NVR and activated instantly, making installation faster than ever before
- 24/7 Continuous Recording: Stores up to 10TB of footage from connected cameras to secure your data for quick, convenient access
- Remote Monitoring: The dedicated VIGI app and VIGI Security Manager enable remote monitoring, providing ease and convenience
- Two-Way Audio: With voice intercom support, carry two-way conversations while watching your feed from anywhere
- Suitable for management
- 80Mbps Video Access Bandwidth: High video access bandwidth ensures your NVR manages more cameras with high resolution
- Based on laboratory testing using VIGI cameras, VIGI NVR can manage up to four 4MP cameras
Network
- Protocol: TCP/IP, DHCP, DNS, NTP, UPnP
- Incoming Bandwidth: 80Mbps
- Outgoing Bandwidth: 60Mbps
Video/Image
- Video Input: 4-Channel IP Video Input, up to 8MP Resolution
- Recording Resolution: 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/, DCIF/2CIF/CIF/QCIF
- HDMI Output Resolution: 1 Channel, Resolution: 3840x2160/30Hz,1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz, 1280x720/60Hz
- VGA Output Resolution: 1 Channel, Resolution: 1920x1080/60Hz,1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz, 1280x720/60Hz
Decoding
- Decoding Format: H.265+/H.265/ H.264+/H.264
- Live View/Playback Resolution: 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/, DCIF/2CIF/CIF/QCIF
- Synchronous Playback: 4 Channel
- Capability: 2-ch @ 8MP, 4-ch @ 4MP
Hard Disk
- SATA: 1 SATA Interface
- Capacity: Up to 10TB
Interfaces
- Network Interface: 1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
- USB Interface: 2× USB2.0
