- IP65 structure
- Lightning and surge protection
- Antifrost hood cover 99% beam blocking stability A.G.C. circuit
- Adjustable beam interruption time
Manufacturer overview
AX-130TN Outdoor IR beam, single channel
40m outdoor AIR beam hardwired
- Hardwired dual beam set
- 99% beam blocking stability
- IP65 structure with high sealing rubber packing
- High grade spherical lens
Specifications
| Model Code |
AX-130TN |
| Detection method |
Twin Channel |
| Detection Coverage |
40m |
| Detectable speed |
Selectable between 50, 100, 250, and 500 msec. |
| Power input |
10.5 - 28VDC |
| Alarm period |
2 sec. (±1) nominal |
| Alarm output (R) |
N.C./N.O. 28 VDC 0.2 A max. |
| IP rating |
IP65 |
| Installation Method (indoor/outdoor) |
Outdoor |
| Operation temperature |
-35°C to +60°C Use the optional heating unit (HU-3) under the environment of -25°C or less minus. |
| Weight |
650 g |
| Dimensions |
170 mm x 65 mm x 69.5 mm |
