5MP HDCVI EYEBALL CAMERA

• Pixel : 5MP
• Image Sensor : 5MP CMOS
• Max. Resolution 2880 (H) × 1620 (V)
• Scanning System : Progressive
• Electronic Shutter Speed
  • PAL: 1/3 s–1/100000 s
  • NTSC: 1/4 s–1/100000 s
• Min. Illumination
  • 0.001 lux@F1.0 (Color, 30 IRE)
  • 0.0001 lux@F1.0 (B/W, 30 IRE)
  • 0 lux (Illuminator on)
• S/N Ratio : >65dB
• Illumination Distance
• IR: 40 m (131.23 ft)
• Warm light: 40 m (131.23 ft)
• Illuminator On/Off Control Auto; manual
• Illuminator Number
  • 2 (IR light)
  • 2 (Warm light)
• Pan/Tilt/Rotation Range
  • Pan: 0°–360°
  • Tilt: 0°–78°
  • Rotation: 0°–360°

Lens

• Lens Type : Fixed-focal
• Lens Mount : M12
• Focal Length : 2.8 mm
• Max. Aperture : F1.0
• Field of View : 2.8 mm: H: 111°; V: 57°; D: 131°
• Iris Control : Fixed
• Close Focus Distance : 2.8 mm: 1.5 m (4.92 ft)

DORI Distance

• Lens : 2.8 mm
• Detect : 66.0 m (216.54 ft)
• Observe : 26.4 m (86.61 ft)
• Recognize : 13.2 m (43.31 ft)
• Identify : 6.6 m (21.65 ft)

Video

• Video Frame Rate
  • CVI:
  • PAL: 5M@25 fps; 4M@25 fps; 1080p@25 fps
  • NTSC: 5M@25 fps; 4M@30 fps; 1080p@30 fps;
  • AHD:
  • PAL: 4M@25 fps;
  • NTSC: 4M@30 fps;
  • TVI:
  • PAL: 4M@25 fps;
  • NTSC: 4M@30 fps;
  • CVBS:
  • PAL: 960H;
  • NTSC: 960H
• Resolution
  • 5M (2880 × 1620);
  • 4M (2560 × 1440);
  • 1080p (1920 × 1080);
  • 960H (960 × 576/960 × 480)
