USB TYPE C 11 IN 1 DOCK- 11IN1DOCK
Product Name: USB C Hub Multiport Adapter
Material: Aluminum + ABS
Application: USB C Device
Usage: Multiuse
Type:11 in 1 USB C Hub
Input: USB3.1 (Type-C)
Output: Type C (only Charge), USB3.0, HD x 4, Audio 3.5, SD/TF Reader, RJ45 Gigabit
Power Rate: 87W(max)
Input Voltage: 5-20V
Input Current: 3A Output voltage: 5V
Output Current: 0.9A
Transmission Rate: 5Gbps
Resolution: 1080P- 60Hz 3840P-30Hz
Applicable System: for Mac OS; for WINDOWS; for Linux
Interface performance:
USB3.0 Interface, 5V/0.9A, 5GBPS Transfer Rate, backward Compatible with USB2.0, Plug and Play
LAN: USB3.0 1000Mbps
TF Card, USB2.0/480bps Transmission, Plug and Play
Type C Interface, PD3.0 Protocol Power Output: 5V-20V/5A
Operating Temperature: 20-60 Degrees Celsius
Support HD x 2K1080P/4K3840 x2160-30Hz
Applicable Models:
For APPLE Full Range of TYPE-C Interface Computers (2015-2020)
For Xiaomi with TYPE-C Port Notebook
For Lenovo with TYPE-C Port Notebook, for GOOGLE with TYPE-C port notebook
For DELL with TYPE-C Port Notebook, for HP with TYPE-C Port Notebook
For Huawei with TYPE-C Notebook, etc.
Disclaimer
This Docking Stations HDMI Video Output Requires The Host Laptops Type C Port To Support DisplayPort Alt Mode Or Thunderbolt 3/4 Video Output.
Hardware & Graphics Limitations:Most Gaming Laptops (including but not limited to Dell, Lenovo, HP, Acer, ASUS) use Hybrid Graphics (Integrated + Discrete GPU).
By Default, Type C Video runs on the Integrated GPU
When Switching to Discrete GPU-only (direct) Mode or High-Performance Mode, the Integrated GPUs Video Output may be disabled by the System, resulting in no HDMI Signal via the Dock, while USB Data Functions remain normal.
No Universal Compatibility:Not all Type C Ports Support Video Output. Some Low-End or Business Laptops are equipped with Data-Only Type C Ports (Marked SSOnly, no D or Thunderbolt Logo) that do not carry Video Signals at all.
User Responsibility: Before Purchase, Please Verify Your Laptops Type C Specifications And graphics Mode Settings With The Manufacturer.
We Do Not Guarantee 100% Compatibility With All laptops, And We Shall Not Be Liable For Any Incompatibility Issues Arising From The Laptops Hardware Design, BIOS/UEFI Settings, Or Graphics Driver Configurations.
