ASUS PRIME B650-PLUS. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen™ 3, AMD Ryzen™ 7, AMD Ryzen 9 7th Gen. Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 10. Ethernet interface type: 2.5 Gigabit Ethernet. Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: AMD
Network
| Wi-Fi |
N |
| Ethernet LAN |
Y |
| Ethernet interface type |
2.5 Gigabit Ethernet |
Weight & dimensions
Processor
| Processor manufacturer |
AMD |
| Processor socket |
Socket AM5 |
| Supported processor sockets |
Socket AM5 |
| Compatible processor series |
AMD Ryzen 3,AMD Ryzen 7,AMD Ryzen 9 7th Gen |
Memory
| Maximum internal memory |
128 |
| ECC |
Y |
| Number of memory slots |
4 |
| Memory slots type |
DIMM |
| Non-ECC |
Y |
| Unbuffered memory |
Y |
| Memory channels |
Dual-channel |
| Supported memory types |
DDR5-SDRAM |
| Supported memory clock speeds |
4800,5000,5200,5400,5600,5800,6000,6200,6400 |
| Supported memory clock speed (max) |
6400 |
Graphics
| Parallel processing technology support |
Not supported |
Features
| Component for |
PC |
| Motherboard form factor |
ATX |
| Power source type |
ATX |
| Motherboard chipset family |
AMD |
| Audio output channels |
7.1 |
| Windows operating systems supported |
Windows 10,Windows 11 x64 |
| Motherboard chipset |
AMD B650 |
Packaging content
| Cables included |
SATA |
| User guide |
Y |
Packaging data
| Package depth |
373 |
| Package height |
68 |
| Package width |
338 |
| Package weight |
1350 |
Expansion slots
| Number of M.2 (M) slots |
2 |
| PCI Express x16 (Gen 4.x) slots |
2 |
| PCI Express x4 (Gen 1.x) slots |
2 |
Internal I/O
| USB 2.0 connectors |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
2 |
| Number of chassis fan connectors |
3 |
| TPM connector |
Y |
| Number of SATA III connectors |
4 |
| Front panel audio connector |
Y |
| ATX Power connector (24-pin) |
Y |
| CPU fan connector |
Y |
| EPS power connector (8-pin) |
Y |
| 12V power connector |
Y |
| RGB LED pin header |
Y |
| Number of COM connectors |
1 |
| Thunderbolt headers |
1 |
Rear panel I/O ports
| USB 2.0 ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| HDMI ports quantity |
1 |
| Headphone outputs |
1 |
| Microphone in |
Y |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| S/PDIF out port |
Y |
| DisplayPorts quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
3 |
| DisplayPort version |
1.4 |
| HDMI version |
2.1 |
| Line-in |
Y |
Storage controllers
| RAID levels |
0,1,10 |
| RAID support |
Y |
| Supported storage drive types |
HDD & SSD |
| Supported storage drive interfaces |
M.2,SATA III |
BIOS
| BIOS type |
UEFI AMI |
| BIOS memory size |
256 |
Other features
| Number of M.2 (E) slots |
1 |
| Back-to-BIOS button |
Y |
